ProPAC-G1 ProPAC-S1 ProPAC-G2 ProPAC-S2 ProPAC-TR

- Prevents mal-function or non-function.
- Has a structure having a great resistance to noise.

  - Uses a standard protocol Modbus.
  - Speedy data transmission rate with a main system
  - Use of ProNET-iMC enables high-speed communication.

  - Voltage/current: (+/-) 0.5%
  - Active/reactive power: (+/-) 1.0%
  - Active/reactive energy: (+/-) 1.5%

  - Simplifies wiring by using sufficient DI contact points.
  - Up to 80 characters can be displayed using 4-line LCD.
  - Includes SOE function by default which records and saves events.
  - Has an auto screen switch function to check measurement values, and a convenient menu structure.
  - You can identify a breaker replacement timing by providing the information on the times of breaker activations
    ａnd conducting period

Item		ProPAC-G1	ProPAC-S1	ProPAC-G2	ProPAC-S2	ProPAC-TR


Relay Elements		Under voltage	Under voltage	Over-current	Over-current	Over-current
		Over-current	Over-current	(independent 2 units)	(independent 2 units)	Over-current ground
		Over-current ground	Over-voltage	Over-voltage ground	Selective ground	Percentage differential
		Over-voltage	Over-voltage ground	(independent 2 units)	(independent 2 units)	Instantaneous differential
		Over-voltage ground	Selective ground

Display	Measurement Items	Current, voltage, frequency, power factor, active power/energy, reactive power/energy

	Display unit	LCD(4 lines x 20 char. : 123.5 x 43.0mm)

Input output	Digital input	10 pts.	10 pts.	10 pts.	10 pts.	10 pts.

	Digital output	9 pts.	9 pts.	9 pts.	9 pts.	8 pts.

	Analog input	PT : 4 pts. CT : 4 pts.	PT : 4 pts. CT : 4 pts.	PT : 3 pts. CT : 8 pts.	PT : 4 pts. CT : 8 pts.	PT : 3 pts. CT : 7 pts.

Comm.	RS-422/485 (4/2 Wire)	1 port

	RS232	1 port

Dimensions (W x H x D:mm)		325 x 175 x 215		375 x 175 x 215

Item		ProPAC


Control power		AC 70 ~ 250V / DC 110 ~ 350V

Digital input		100 ~ 130 VDC / 10 ~ 15 mA / point

Digital output		Resistive load : AC 250V, 10A DC 30V, 10A COSØ=1.0

		Inductive load : AC 250V, 7.5A DC 30V, 5A COSØ=0.4 L/R = 7ms

Analog Input	Current	CT : 5A, ZCT : 1.5mA

	Voltage	PT : 110V, GPT : 190V

	Burden	PT : 0.5VA or below, CT : 1.0 VA or below
